Motorola DS 6708 (Symbol) Barcode Scanner

The handheld DS6708 combines a 1D and 2D barcode scanner, maximizing employee productivity and streamlining business processes in the retail store, post office, pharmacy or manufacturing floor. The DS6708 reduces capital and operating expenses by eliminating the need to purchase separate devices to read different barcode symbologies. Remote scanner management capability further reduces the total cost of ownership, while multiple interface options makes for easy installation anywhere.

Technical Information

Barcode Dimension:
- 1D
- 2D
Scan Pattern: Omni-directional
Connectivity Technology: Cable
Image Sensor: Imager
Barcode Symbology Supported:
- 1-D:
- UPC/EAN and with supplementals
- Code 39
- Code 39 Full ASCII
- Tri-optic Code 39
- GS1DataBar (formerly RSS)
- Code 128
- Code 128 Full ASCII
- GS1-128 (formerly UCC/EAN-128)
- Code 93
- Codabar (NW1)
- Interleaved 2 of 5
- Discrete 2 of 5
- MSI
- Codell
- IATA
- Bookland EAN
- Code 32
- PDF417 (and Variants):
- PDF417
- MicroPDF417 and composite codes
- Postal:
- U.S. Postnet and Planet
- U.K.
- Japan
- Australian
- Dutch
- 2-D:
- MaxiCode
- DataMatrix (ECC 200)
- QR Code
- 1-D:
- UPC/EAN and with supplementals
- Code 39
- Code 39 Full ASCII
- Tri-optic Code 39
- GS1DataBar (formerly RSS)
- Code 128
- Code 128 Full ASCII
- GS1-128 (formerly UCC/EAN-128)
- Code 93
- Codabar (NW1)
- Interleaved 2 of 5
- Discrete 2 of 5
- MSI
- Codell
- IATA
- Bookland EAN
- Code 32
- PDF417 (and Variants):
- PDF417
- MicroPDF417 and composite codes
- Postal:
- U.S. Postnet and Planet
- U.K.
- Japan
- Australian
- Dutch
- 2-D:
- MaxiCode
- DataMatrix (ECC 200)
- QR Code
Depth of Field:
- 1.10″ – 6.50″@5 mil – Code 39
- 0.50″ – 9.70″@13 mil – 100% UPC/EAN
- 0.50″ – 15.20″@20 mil – Code 39
- 0.90″ – 7″@10 mil – PDF417
- 1.10″ – 7.50″@10 mil – Data Matrix

General Information

Product Type: Handheld Barcode Scanner
Brand Name: Motorola
Manufacturer: Motorola, Inc
Product Model: DS6708
Product Name: Symbol DS6708 Barcode Reader
Product Line: Symbol

Physical Characteristics

Height: 6.6″
Width: 2.8″
Depth: 4.7″
Color: Black
Weight (Approximate): 6.40 oz

Interfaces/Ports

Host Interface: Multi-interface

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS
Additional Information:
- Supported Interfaces:
- RS-232
- USB
- IBM 468x/469x
- Keyboard Wedge
